May 2, 2024

Self-Reflection on Database Schema Design

sql

Preface

Recently I have developed a mobile application for the company I am working at. I am grateful to have an oppurtunity and precious experience to design the whole system from zero.

What I failed

  • Sparsity of Table. Some data looks identitcal, I have therefore tried to mix two interfaces into one table, for example:

    where the type of this record depends on SessionType, which determines whether we use isDraftInstantIssue or isDraftReply. It causes some of the column being always null (i.e., sparsity), and it causes confusion when do we use these booleans.

    From this lesson I should have made additional two tables named

    • InstantIssueDetail and
    • ReplyDetail,

    and link these two tables to the original table via

    • InstantIssueDetail.session_id and
    • ReplyDetail.session_id
      respectively. The new tables group all the type-specific data.
  • Similar to the above case. A message can be of type Image, Voice, Text, and forturnately I can avoid the sparsity timely:

  • Didn't Stop Bad Design at the Beginning (Data Duplication). In the past we had a tech lead designing a UserRegistration table (where User table has been made already) which serves as an intermediate table before User.

    However 90% of data are the same. This results in unpredictable extra amount of works as every time we deal with registration we need to look at two tables.

    If we want to select data, we need to case, when, then, else, end many times.

What I succeeded

Researched on various ORMs, youtube videos on those frameworks, pros and cons, combining the experience with sql tutorial from other languages, eventually

  • Adopted Prisma as a table migration tool in light of Flyway in spring boot and Goose in golang.

  • Used Kysely as a type-safe query builder.

  • Standardized the approach to version all the schema changes in database, and reproduce all the changes to different environments.

Our product works well with the database and developers can easily write their query with good semantic meaning, for example:

which an ORM cannot provide. Note that a table carries different meaning in differnent context!
