1. Queues Fundamentals

1// Service A (Producer)
2async function serviceA() {
3    const channel = await connection.createChannel();
4    await channel.assertExchange('orders_exchange', 'topic');
5
6    // Only publishes, doesn't need to know about queues
7    channel.publish('orders_exchange', 'order.created',
8        Buffer.from('new order'));
9}
10
11// Service B (Consumer)
12async function serviceB() {
13    const channel = await connection.createChannel();
14    await channel.assertExchange('orders_exchange', 'topic');
15    await channel.assertQueue('order_processing_queue');
16    await channel.bindQueue('order_processing_queue', 'orders_exchange',
17        'order.created');
18
19    channel.consume('order_processing_queue', msg => {
20        // Process order
21    });
22}

2. Queues Structure

3. File Structure

Let's explore these files one by one.

3.1. QueueName.ts

1enum QueueName {
2    LLM_SUMMARY_STEP = "LLM_SUMMARY_STEP",
3    LLM_TRANSLATION_STEP = "LLM_TRANSLATION_STEP",
4    LLM_REPLY_STEP = "LLM_REPLY_STEP",
5    INSERT_ALGOLIOA = "INSERT_ALGOLIOA",
6    UPDATE_ALGOLIA = "UPDATE_ALGOLIA",
7    FLASK_EXCEL_GENERATION = "FLASK_EXCEL_GENERATION",
8    SNOOZE_AND_PIN = "SNOOZE_AND_PIN",
9    SNOOZE_AND_PIN_DEAD_LETTER = "SNOOZE_AND_PIN_DEAD_LETTER",
10    EXPORT_REPORT = "EXPORT_REPORT",
11    LLM_USAGE_LOG = "LLM_USAGE_LOG",
12    LLM_IMPACT_UPDATE = "LLM_IMPACT_UPDATE"
13}
14
15export default QueueName;

3.2. RoutingKey.ts

1enum QueueName {
2    LLM_SUMMARY_STEP = "LLM_SUMMARY_STEP",
3    LLM_TRANSLATION_STEP = "LLM_TRANSLATION_STEP",
4    LLM_REPLY_STEP = "LLMREPLY_STEP",
5    INSERT_ALGOLIOA = "INSERT_ALGOLIOA",
6    UPDATE_ALGOLIA = "UPDATE_ALGOLIA",
7    FLASK_EXCEL_GENERATION = "FLASK_EXCEL_GENERATION",
8    SNOOZE_AND_PIN = "SNOOZE_AND_PIN",
9    SNOOZE_AND_PIN_DEAD_LETTER = "SNOOZE_AND_PIN_DEAD_LETTER",
10    EXPORT_REPORT = "EXPORT_REPORT",
11    LLM_USAGE_LOG = "LLM_USAGE_LOG",
12    LLM_IMPACT_UPDATE = "LLM_IMPACT_UPDATE"
13}
14
15export default QueueName;

3.3. channels.ts

1import amqplib, { Channel, Replies } from "amqplib";
2import logger from "../util/logger";
3import QueueName from "./QueueName";
4import queueBinding from "./queueBinding";
5
6const AMQP_URL = process.env.AMQP_URL || ""
7
8export const NORMAL_EXCHANGE = "Billie"
9export const GENERAL_DEAD_EXCHANGE = "GENERAL_DEAD_EXCHANGE"
10
11const Q_CAPACITY = Number(process.env.Q_CAPACITY || "10");
12
13type ChannelRef = { current: Channel | null };
14
15const llmTaskChannelRef: ChannelRef = { current: null };
16const normalTaskChanenlRef: ChannelRef = { current: null };
17
18
19const getLLMTaskChannel = () => llmTaskChannelRef.current;
20const getNormalTaskChannel = () => normalTaskChanenlRef.current;
21
22const queues: { [k in QueueName]?: Replies.AssertQueue } = {};
23
24const getQueue = (queueName: QueueName) => queues?.[queueName];
25
26const initChannels = async (consumptions: (() => void)[]) => {
27    // create channels
28    const connection = await amqplib.connect(AMQP_URL);
29    const llmTaskChannel = await connection.createChannel();
30    const normalTaskChannel = await connection.createChannel();
31
32    llmTaskChannel.prefetch(Q_CAPACITY);
33    llmTaskChannelRef.current = llmTaskChannel;
34    normalTaskChanenlRef.current = normalTaskChannel;
35
36    try {
37        await llmTaskChannel.assertExchange(NORMAL_EXCHANGE, "direct", { durable: true });
38        await llmTaskChannel.assertExchange(GENERAL_DEAD_EXCHANGE, "direct", { durable: true });
39    } catch (err) {
40        console.log(err);
41    }
42
43    await queueBinding({ queues, llmTaskChannel, normalTaskChannel });
44
45    for (const consumption of consumptions) {
46        consumption();
47    }
48
49    logger.info("Channels Inited")
50}
51
52export default {
53    getQueue,
54    getLLMTaskChannel,
55    getNormalTaskChannel,
56    initChannels
57}

Here queueBinding and consumptions are the most important components of our queue system.

3.4. queueBinding.ts

1import { Channel, Replies } from "amqplib";
2import QueueName from "./QueueName";
3import RoutingKey from "./RoutingKey";
4import { GENERAL_DEAD_EXCHANGE, NORMAL_EXCHANGE } from "./channels";
5const SNOOZE_PIN_TTL = Number(process.env.SNOOZE_PIN_TTL || "604800000");
6
7type KeyBindingConfig<Q, R> = {
8    queueName: Q
9    routingKey: R,
10    channel: Channel,
11    exchange: string,
12    deadLetter?: {
13        deadLetterExchange?: string,
14        deadLetterRoutingKey?: R,
15        messageTtl?: number
16    }
17}
18
19const bind = async (
20    queues: { [key in QueueName]?: Replies.AssertQueue },
21    config: KeyBindingConfig<QueueName, RoutingKey>
22) => {
23    const { channel, queueName, exchange, routingKey,
24        deadLetter = {}
25    } = config;
26    const q = await channel.assertQueue(queueName, {
27        durable: true,
28        ...deadLetter
29    });
30    queues[queueName] = q;
31    await channel.bindQueue(queueName, exchange, routingKey);
32}
33
34const queueBinding = async (args: {
35    queues: { [key in QueueName]?: Replies.AssertQueue },
36    llmTaskChannel: Channel,
37    normalTaskChannel: Channel
38}) => {
39    const { queues, llmTaskChannel, normalTaskChannel } = args;
40
41    const queueConfigs: KeyBindingConfig<QueueName, RoutingKey>[] = [
42        {
43            queueName: QueueName.LLM_SUMMARY_STEP,
44            routingKey: RoutingKey.LLM_SUMMARY_STEP,
45            channel: llmTaskChannel,
46            exchange: NORMAL_EXCHANGE
47        },
48        {
49            queueName: QueueName.LLM_TRANSLATION_STEP,
50            routingKey: RoutingKey.LLM_TRANSLATION_STEP,
51            channel: llmTaskChannel,
52            exchange: NORMAL_EXCHANGE
53        },
54        {
55            queueName: QueueName.LLM_REPLY_STEP,
56            routingKey: RoutingKey.LLM_REPLY_STEP,
57            channel: llmTaskChannel,
58            exchange: NORMAL_EXCHANGE
59        },
60        {
61            queueName: QueueName.SNOOZE_AND_PIN,
62            routingKey: RoutingKey.SNOOZE_AND_PIN,
63            channel: normalTaskChannel,
64            exchange: NORMAL_EXCHANGE,
65            deadLetter: {
66                deadLetterExchange: GENERAL_DEAD_EXCHANGE,
67                deadLetterRoutingKey: RoutingKey.SNOOZE_AND_PIN_DEAD_LETTER,
68                messageTtl: SNOOZE_PIN_TTL
69            }
70        },
71        {
72            queueName: QueueName.SNOOZE_AND_PIN_DEAD_LETTER,
73            routingKey: RoutingKey.SNOOZE_AND_PIN_DEAD_LETTER,
74            channel: normalTaskChannel,
75            exchange: GENERAL_DEAD_EXCHANGE,
76        },
77        {
78            queueName: QueueName.INSERT_ALGOLIOA,
79            routingKey: RoutingKey.INSERT_ALGOLIOA,
80            channel: normalTaskChannel,
81            exchange: NORMAL_EXCHANGE,
82        },
83        {
84            queueName: QueueName.UPDATE_ALGOLIA,
85            routingKey: RoutingKey.UPDATE_ALGOLIA,
86            channel: normalTaskChannel,
87            exchange: NORMAL_EXCHANGE,
88        },
89        {
90            queueName: QueueName.FLASK_EXCEL_GENERATION,
91            routingKey: RoutingKey.FLASK_EXCEL_GENERATION,
92            channel: normalTaskChannel,
93            exchange: NORMAL_EXCHANGE,
94        },
95        {
96            queueName: QueueName.EXPORT_REPORT,
97            routingKey: RoutingKey.EXPORT_REPORT,
98            channel: normalTaskChannel,
99            exchange: NORMAL_EXCHANGE,
100        },
101        {
102            queueName: QueueName.LLM_USAGE_LOG,
103            routingKey: RoutingKey.LLM_USAGE_LOG,
104            channel: normalTaskChannel,
105            exchange: NORMAL_EXCHANGE
106        },
107        {
108            queueName: QueueName.LLM_IMPACT_UPDATE,
109            routingKey: RoutingKey.LLM_IMPACT_UPDATE,
110            channel: normalTaskChannel,
111            exchange: NORMAL_EXCHANGE
112        }
113    ]
114
115    for (const queueConfig of queueConfigs) {
116        await bind(queues, queueConfig);
117    }
118}
119
120export default queueBinding;

3.5. consumptions.ts

1import llmSummaryQueue from "./llmSummaryQueue";
2import algoliaUpdateQueue from "./algoliaUpdateQueue";
3import excelGenReqToFlaskQueue from "./excelGenReqToFlaskQueue";
4import llmReplyQueue from "./llmReplyQueues";
5import llmTranslationQueue from "./llmTranslationQueue";
6import llmUsageLogQueue from "./llmUsageLogQueues";
7import snoozeAndPinDeadLetterQueue from "./snoozeAndPinDeadLetterQueue";
8import snoozeAndPinQueue from "./snoozeAndPinQueue";
9import llmImpactUpdateQueue from "./llmImpactUpdateQueue";
10
11export default [
12  algoliaUpdateQueue.initConsumption,
13  excelGenReqToFlaskQueue.initConsumption,
14  llmReplyQueue.initConsumption,
15  llmSummaryQueue.initConsumption,
16  llmTranslationQueue.initConsumption,
17  llmUsageLogQueue.initConsumption,
18  snoozeAndPinDeadLetterQueue.initConsumption,
19  // snoozeAndPinQueue.initConsumption,  <---- don't add this
20  llmImpactUpdateQueue.initConsumption,
21];

initConsumption is a method of our custom MessageQueue class which simplify our code by templating the boilerplate code:

3.6. MessageQueue Class (model/MessageQueue.ts)

1import { Channel } from "amqplib";
2import { MessageErrorModel } from "../../db/mongo/models/MessageErrorLog";
3import gmailService from "../../service/gmailService";
4import logger from "../../util/logger";
5import QueueName from "../QueueName";
6import RoutingKey from "../RoutingKey";
7import channels, { NORMAL_EXCHANGE } from "../channels";
8
9const ERROR_EMAIL_RECEIVER = process.env.ERROR_EMAIL_RECEIVER;
10const env = process.env.env;
11
12export default class MessageQueue<MessageType> {
13    private queueName: QueueName;
14    private routingKey: RoutingKey;
15    private channel: () => (Channel | null);
16    private exchange = NORMAL_EXCHANGE;
17    public consumption?: (decoded: MessageType) => void | Promise<void>;
18
19    constructor(args: {
20        queueName: QueueName,
21        routingKey: RoutingKey,
22        channel: () => (Channel | null),
23        consumption?: (decoded: MessageType) => void | Promise<void>,
24        exchange?: string
25    }) {
26        const { exchange = NORMAL_EXCHANGE } = args
27        this.queueName = args.queueName;
28        this.routingKey = args.routingKey;
29        this.channel = args.channel;
30        this.consumption = args.consumption;
31        this.exchange = exchange;
32    }
33
34    public publish = (msg: MessageType) => {
35        const refinedMsg = msg as MessageType & { routingKey: RoutingKey };
36        refinedMsg.routingKey = this.routingKey;
37        const msg_ = JSON.stringify(refinedMsg);
38
39        this.channel()?.publish(
40            this.exchange,
41            this.routingKey,
42            Buffer.from(msg_)
43        );
44    }
45
46    public initConsumption = () => {
47        const q = channels.getQueue(this.queueName);
48        if (!this.channel()) {
49            throw new Error(`llmTaskChannel cannot be established`);
50        }
51        if (!q) {
52            throw new Error(` q: ${this.routingKey} cannot be established`);
53        }
54        this.channel()?.consume(q.queue, (msg) => {
55            const msg_ = msg?.content.toString();
56            const decodedMsg: MessageType = JSON.parse(msg_ || '{ "message": "msg_ is null" }');
57            if (!msg?.content) {
58                logger.info("null message");
59                return;
60            }
61            try {
62                logger.info(`[${this.routingKey}]: processing msg ${msg_}`)
63                const result = this.consumption?.(decodedMsg);
64                if (result instanceof Promise) {
65                    // synchronous call cannot catch the error thrown inside a promise.
66                    result
67                        .then(() => {
68                            this.channel()?.ack(msg);
69                        }).catch(err => {
70                            const errorLog = new MessageErrorModel({
71                                msg: {
72                                    err: err?.message || "",
73                                    step: (decodedMsg as { routingKey?: string }).routingKey || "",
74                                    param: decodedMsg
75                                }
76                            })
77                            gmailService.sendEmail({
78                                to: ERROR_EMAIL_RECEIVER || "",
79                                html: `<div>
80                        <div>Error Message:
81                            <p/>
82                            <div>
83                                ${JSON.stringify(decodedMsg, null, 2)}
84                            </div>
85                            <p>The same message is also logged in mongodb.</p>
86                        </div>`,
87                                subject: `Error message from ${env?.toUpperCase()} environment`,
88                                text: `Error message from ${env?.toUpperCase()} environment`
89                            })
90                            errorLog.save().then(() => {
91                                this.channel()?.nack(msg, false, false);
92                            })
93                        });
94                } else {
95                    this.channel()?.ack(msg);
96                }
97            } catch (err) {
98                const errorLog = new MessageErrorModel({
99                    msg: {
100                        err: (err as { message?: string })?.message || "",
101                        step: (decodedMsg as { routingKey?: string }).routingKey || "",
102                        param: decodedMsg
103                    }
104                })
105                gmailService.sendEmail({
106                    to: ERROR_EMAIL_RECEIVER || "",
107                    html: `<div>
108                        <div>Error Message:
109                            <p/>
110                            <div>
111                                ${JSON.stringify(decodedMsg, null, 2)}
112                            </div>
113                            <p>The same message is also logged in mongodb.</p>
114                        </div>`,
115                    subject: `Error message from ${env?.toUpperCase()} environment`,
116                    text: `Error message from ${env?.toUpperCase()} environment`
117                })
118                errorLog.save().then(() => {
119                    this.channel()?.nack(msg, false, false);
120                })
121            }
122        }, { noAck: false });
123    }
124}

Here the try-catch logic seems a bit repetitive.
But note that a normal try-catch would not catch the error thrown inside a promise, therefore we need to repeatedly catch the error.
Here we reject a message by either throwing an error explicitly (for example, we might want to try catch to execute custom logging logic, and then throw the error again)
or by letting the program throw any error.

4. Example of Queues

Note that by using MessageQueue class we can pay all our attention to writing consumption logic.

4.1. Normal Task Queue

4.1.1. excelGenReqToFlaskQueue

1import LLMStatus from "../../constants/LLMStatus";
2import { db } from "../../db/kysely/database";
3
4import { MessageErrorModel } from "../../db/mongo/models/MessageErrorLog";
5import { SummaryLangChoice } from "../../dto/dto";
6import chatService from "../../service/chatService";
7import RedisUtil from "../../util/RedisUtil";
8import QueueName from "../QueueName";
9import RoutingKey from "../RoutingKey";
10import channels from "../channels";
11import MessageQueue from "../model/MessageQueue";
12
13const llmTaskChannel = () => channels.getLLMTaskChannel();
14
15const excelGenReqToFlaskQueue = new MessageQueue<{
16    roomId: string, lang: SummaryLangChoice
17}>({
18    channel: llmTaskChannel,
19    queueName: QueueName.FLASK_EXCEL_GENERATION,
20    routingKey: RoutingKey.FLASK_EXCEL_GENERATION,
21    consumption: async (decoded) => {
22        const { lang, roomId } = decoded;
23        try {
24            await chatService.dispatchExcelGenerationTaskToFlask(roomId, lang);
25            await RedisUtil.setLLMStatus(roomId, LLMStatus.FINISHED);
26        } catch (err) {
27            const errorLog = new MessageErrorModel({
28                msg: {
29                    err: err,
30                    step: "excelGenReqToFlaskQueue",
31                    param: decoded
32                }
33            })
34            // only session will use this excel generation function
35            await db.updateTable("MessagesSession")
36                .set({ isLiveEnded: false }).where("MessagesSession.id", "=", roomId).execute();
37            await errorLog.save();
38            RedisUtil.setLLMStatus(roomId, LLMStatus.FAILED);
39            throw err;
40        }
41    }
42})
43
44export default excelGenReqToFlaskQueue;

4.2. Dead-Letter Queues

4.2.1. snoozeAndPinQueue.ts

Note that this queue is supposed to be a delayed task queue, no consumption should be inited. Otherwise we have to at least ack, nack, reject which violates our purpose to let the message expire automatically.

1import { SnoozeAndPinMessage } from "../../dto/dto";
2import QueueName from "../QueueName";
3import RoutingKey from "../RoutingKey";
4import channels from "../channels";
5import MessageQueue from "../model/MessageQueue";
6
7const normalTaskChannel = () => channels.getNormalTaskChannel();
8
9const snoozeAndPinQueue =  new MessageQueue<SnoozeAndPinMessage> ({
10    channel: normalTaskChannel,
11    queueName: QueueName.SNOOZE_AND_PIN,
12    routingKey: RoutingKey.SNOOZE_AND_PIN,
13});
14
15export default snoozeAndPinQueue;

Here we have leave the consumption field empty and we have not put it inside the list of consumptions.ts.

4.2.2. snoozeAndPinDeadLetterQueue.ts

According to our configuration in queueBinding.ts, after SNOOZE_PIN_TTL ms, the message from QueueName.SNOOZE_AND_PIN will be redirected to RoutingKey.SNOOZE_AND_PIN_DEAD_LETTER via GENERAL_DEAD_EXCHANGE exchange.

1import nonDraftsCache from "../../caching/nonDraftsCache";
2import { db } from "../../db/kysely/database";
3import { SnoozeAndPinMessage } from "../../dto/dto";
4import QueueName from "../QueueName";
5import RoutingKey from "../RoutingKey";
6import channels from "../channels";
7import MessageQueue from "../model/MessageQueue";
8
9const normalTaskChannel = () => channels.getNormalTaskChannel();
10
11const snoozeAndPinDeadLetterQueue = new MessageQueue<SnoozeAndPinMessage>({
12    channel: normalTaskChannel,
13    queueName: QueueName.SNOOZE_AND_PIN_DEAD_LETTER,
14    routingKey: RoutingKey.SNOOZE_AND_PIN_DEAD_LETTER,
15    consumption: async (decoded) => {
16        const { sessionId, channelId, isAdmin } = decoded;
17        await db.updateTable("MessagesSession")
18            .set({
19                prioritizedOrSnoozedAt: 0,
20                sortingTimestamp: eb => eb.selectFrom("MessagesSession as NewSession")
21                    .select("NewSession.createdAt")
22                    .where("NewSession.id", "=", sessionId)
23            })
24            .where("MessagesSession.id", "=", sessionId)
25            .execute();
26
27        const { customClearCache } = nonDraftsCache.setCacheKey({ channelId, isAdmin });
28        await customClearCache();
29    }
30});
31
32export default snoozeAndPinDeadLetterQueue;

Contents
