August 29, 2021

Image Augmentation with Custom Dataset Pipeline

tensorflow

Contents

Define Our Mapping Functions to Tensorflow Dataset

Image path to (img, label) format

We start from pre-processing functions that handle the validation dataset and also arbitrary images with which we will feed into our model:

from tensorflow.keras.applications.vgg16 import preprocess_input

autotune = tf.data.experimental.AUTOTUNE

def get_label(file_path):
  return tf.strings.split(file_path, os.path.sep)[-2]

def path_to_imgLabel(file_path):
  label = tf.cast(tf.strings.to_number(get_label(file_path)), dtype=tf.int32)
  img = tf.io.read_file(file_path)
  img = tf.image.decode_jpeg(img, channels=3)
  return img, label

def preprocess_train_image(img, label):
  img = tf.image.resize(img, (vgg_img_size, vgg_img_size))
  img = preprocess_input(img)
  return img, label
Image Augmentations I - The Basic Pipeline

Since tf.imaga can just provide us a limited amounts of augmentations to our input data, like tf.image.random_flip_left_right, for a richer resouce of augmentation we try to import albumentations library:

from albumentations import (
  Compose,
  RandomBrightnessContrast,
  ImageCompression,
  HueSaturationValue,
  HorizontalFlip,
  Rotate
)

and define our transforms that will be applied to images when we take a batch of images from generator:

transforms = Compose([
  Rotate(limit=40),
  RandomBrightnessContrast(p=0.5),
  ImageCompression(quality_lower=85, quality_upper=100, p=0.5),
  HueSaturationValue(hue_shift_limit=20, sat_shift_limit=30, val_shift_limit=20, p=0.5),
  HorizontalFlip()
])

We define the data augmentation function (the last line, image_augmentation) that will take img, label as arguments:

from functools import partial

def aug_fn(image, img_size):
  data = {"image": image}
  aug_data = transforms(**data)
  aug_img = aug_data["image"]
  aug_img = tf.image.resize(aug_img, size=[img_size, img_size])
  return aug_img

def image_augmentation(image, label, img_size):
  aug_img = tf.numpy_function(func=aug_fn, inp=[image, img_size], Tout=tf.float32)
  img_shape=(img_size, img_size, 3)
  aug_img.set_shape(img_shape)
  return aug_img, label

image_augmentation = partial(image_augmentation, img_size=vgg_img_size)
Image Augmentations II - Same Augmentations to a pair of Images

In image segmentations our image augmentations have to be carried out equally to both the images and masks.

Suppose our image training dataset, ./cars, has a associated mask dataset, ./mask, we pair them as follows:

dataset = tf.data.Dataset.list_files("./cars/*")

def path_to_imgLabel(file_path):
  mask_filepath = tf.strings.regex_replace(file_path, "cars", "masks" )
  mask_filepath = tf.strings.regex_replace(mask_filepath, ".jpg", "_mask.gif" )

  img = tf.io.read_file(file_path)
  img = tf.image.decode_jpeg(img)

  img = tf.image.resize(img, (img_size, img_size))

  mask = tf.io.read_file(mask_filepath)
  mask = tf.image.decode_gif(mask)
  mask = tf.image.resize(mask, (img_size, img_size))
  mask = tf.reshape(mask, (img_size, img_size, 3))
  mask = tf.reduce_mean(mask, axis=-1, keepdims=True)

  return img, mask

train_data = dataset.map(path_to_imgLabel)

Next we apply color-invariant augmentations to the pair (img, mask)'s and color-related augmentation to img's, for that we define two transformations:

transforms_general = Compose(
  [
    Rotate(limit=40),
    HorizontalFlip(),
  ],
   additional_targets={'mask0': 'image'}
)

transform_color = Compose(
  [
    RandomBrightnessContrast(p=0.5),
    ImageCompression(quality_lower=85, quality_upper=100, p=0.5),
    HueSaturationValue(hue_shift_limit=20, sat_shift_limit=30, val_shift_limit=20, p=0.5),
  ]
)

they kwarg additional_targets={'mask0': 'image'} means that mask0 will share the same set of transformation with image, and after the transformation we can retrieve the transformed mask by the key mask0.

Note the tricky part here. It might be tempting to define additional_targets={'mask': 'image'}, but unfortunately there are 4 reserved keywords that cannot be used as a key in the dictionary for additional_targets.

From documentation these are image, mask, bboxes and keypoints.

Now we define the next pair of functions which bring the transformations above into play:

def aug_fn(image, mask):
  transformed = transforms_general(image=image, mask0=mask)
  image = transformed['image']
  mask = transformed['mask0']

  aug_data = transform_color(image=image)
  image = aug_data['image']
  return image, mask

def image_augmentation(image, mask):
  transformed = tf.numpy_function(func=aug_fn, inp=[image, mask], Tout=[tf.float32, tf.float32])
  aug_img = transformed[0]
  aug_mask = transformed[1]
  aug_img.set_shape((img_size, img_size, 3))
  aug_mask.set_shape((img_size, img_size, 1))

  return aug_img, aug_mask

Beware of the argument Tout above, it has to be a list that specifies the data type of the output. Otherwise OperatorNotAllowedInGraphError would occur since the function has no idea what is the data type that tf.numpy_function will return.

Finish the Pipeline

The strategy of our complete dataset pipeline is to:

  1. take path to img, label;

  2. then map the images by functions taking img, label to img, label multiple times, which depends on the number of mapping we need.

    For example, in the chain of .map(image_augmentation).map(preprocess_train_image) below we are free to remove the augmentation part and leave preprocess_train_image alone (which is what it is initially when there is no augmentation implemented).

train_dataset = tf.data.Dataset.list_files("./train_dataset/*/**") \
.map(path_to_imgLabel) \
.map(image_augmentation, num_parallel_calls=autotune).prefetch(autotune) \
.map(preprocess_train_image, num_parallel_calls=autotune) \
.cache() \
.shuffle(buffer_size) \
.batch(batch_size)

val_dataset = tf.data.Dataset.list_files("./val_dataset/*/**")  \
.map(path_to_imgLabel) \
.map(preprocess_train_image, num_parallel_calls=autotune) \
.cache() \
.batch(batch_size)

Read the Result of Image Augmentation

As usual we import:

import matplotlib.pyplot as plt

and define:

def view_image(ds):
  image, label = next(iter(ds)) # extract 1 batch from the dataset
  image = image.numpy().astype('uint8')
  label = label.numpy().astype('uint8')

  fig = plt.figure(figsize=(22, 22))
  for i in range(20):
    ax = fig.add_subplot(4, 5, i+1, xticks=[], yticks=[])
    ax.imshow(image[i])
    ax.set_title(f"Label: {label[i]}")

Finally we run:

view_image(train_dataset)

Result:
